Electric spray guns adopt built-in motor pressurized atomization without air compressors and hoses, ready for spraying once powered on to support flexible mobile operation without air source restrictions. The lightweight handheld body supports stepless adjustment of paint flow and spray fan width, delivering ultra-fine uniform atomization for smooth brush-free coating. Certain models are equipped with built-in LED auxiliary lights to provide clear vision in dim corners, cabinet interiors and hidden workpieces, greatly improving precision of touch-up and delicate coating. Compatible with latex paint, wood lacquer, clear coat, water-based pigment, disinfectant and other water-based liquids, it features simple operation and easy cleaning, widely used for furniture renovation, wall touch-up, craft coloring, partial paint repair and disinfection spraying, serving as ideal portable coating tools for jobs without air supply.
1. Housing: Integral high-strength engineering plastic, lightweight, impact-resistant and anti-corrosive against paint, low surface temperature during long-time holding.
2. Nozzle Assembly: Stainless steel nozzles with excellent wear resistance and anti-clogging performance, detachable and interchangeable.
3. Paint Cup: Large transparent PP plastic container for visible residual liquid, easy to disassemble and clean without residue buildup.
4. Built-in Motor: Pure copper coil motor with low heat generation and stable power output, no power drop during long continuous spraying.
5. Anti-slip Grip: Ergonomic soft rubber handle to absorb vibration and relieve hand fatigue for prolonged operation.
1. Rated Voltage: 100–120V, 210–230V AC corded type; 18V, 21V rechargeable lithium battery type
2. Motor Power: 400W–850W (corded); 200W–250W (lithium battery powered)
3. Paint Cup Capacity: 800ml–1400ml
4. Standard Interchangeable Nozzle Sizes: 1.0mm, 1.5mm, 1.8mm, 2.0mm, 2.5mm, 3.0mm
5. Adjustable Spray Patterns: 3 modes including round, horizontal fan and vertical fan
6. Applicable Liquid Viscosity: 0–100 DIN seconds, suitable for diluted water-based coatings and disinfection liquids
1. Air source free design, plug-in or battery operated for flexible indoor and outdoor sporadic construction.
2. Dual adjustment of flow rate and spray fan fits both delicate touch-up and large-area coating.
3. Selected versions with LED fill lights eliminate dark blind spots for more accurate fine spraying work.
4. Interchangeable stainless steel nozzles for thin and thick coatings, effectively reducing clogging.
5. Detachable paint cup and nozzle enable quick post-operation cleaning to avoid pipeline blockage from cured paint.
6. Lightweight low-vibration body minimizes wrist fatigue, perfect for household DIY and small engineering coating work.
Wood door & furniture recoloring, local indoor wall repair, craft model painting, auto small component touch-up, window & door anti-rust coating, space disinfection spraying, iron guardrail painting, advertising sample coating.
1. Dilute coatings following instructions and filter impurities to avoid stainless steel nozzle blockage.
2. Test spray fan and paint flow before formal work, adjust spraying distance to prevent sagging or thin coating.
3. Do not spray flammable, highly corrosive or incompatible chemicals to avoid tool damage and safety risks.
4. Thoroughly clean paint cup, nozzle and internal air passages with matched thinner right after each use.
5. Empty and dry residual coating inside pipelines before long-term storage, store in cool, dry and ventilated space.
6. Recharge lithium battery models timely after use; avoid long-term storage with dead battery to extend battery service life.
